Aicsys RCK-308M2 – 3U Rackmount Chassis
The RCK-308M2 3U Rackmount Chassis provides a classy and resourceful solution for a variety of Industrial applications using ATX motherboard. Besides external four 5.25” bays and two 3.5” bays, RCK-308M2 offers two 3.5” shock resistive drive bays; sufficient for applications that use quite significant number of drivers without having to use very bulky 4U chassis. Two levels temperature management relies on two 6cm ball-bearing fan that provide excellent cooling. RCK-308M2 offers two 2.0 USB ports.- 3U 19″ Rackmount Standard Chassis
- Heavy duty Steel, Black
- Supports ATX motherboard
- (4) 5.25″ external, (2) 3.5″ external, and (2) 3.5″ internal Drive Bays
- (2) 2.0 USB ports
- (2) 60mm ball-bearing fan with space for one additional fan
- Dual Lockable Front Doors and Replaceable Air Filters
- Supports 2U & 3U Power supply
Industria / Placas
-
HDD
-
Interfaz
-
USB
Specifications
| Board Support | ATX Motherboard |
|---|---|
| Expansion Slots | 7-Slots for full size add-on cards |
| Drive Bays | (4) 5.25″ and (2) 3.5″ external drives and (2) 3.5″ internal drives |
| Front Panel | (2) USB 2.0 Ports on front panel On/Off Switch and Reset Switch, LED for Power ON/OFF, HDD |
| Power Supply | Supports 2U & 3U Power supply |
|---|---|
| Cooling | (2) 60mm ball-bearing fans |
| Dimensions | 430 (W) x 510 (D) x 132 (H)mm |
| Gross Weight | 13.8kg |
