COM-601
COM Express Type 6 Compact Size intel Braswell SoC (0ºC – 60ºC)- COM Express Type 6 Compact Size
- Intel® Pentium®/Celeron® Braswell SoC Processor
- Supports DDR3L 1333/1600MHz, 2 x SO-DIMM, up to 8GB system memory
- 3 x DDI channels, 1 x eDP channel
- 7 x PCIe x1 Lanes (1 for Intel® I211AT GbE)
- 4 x USB SS, 8 x USB 2.0, 2 x SATA 3
![COM-601](pics_fotosproductos/103/med_full_asrock-iep-9032e-1.jpg)
![COM-601](pics_fotosproductos/103/med_full_asrock-iep-9032e-2.jpg)
![COM-601](pics_fotosproductos/103/med_full_asrock-iep-9032e-3.jpg)
![COM-601](pics_fotosproductos/103/med_full_asrockfondo-blanco.jpg)
![COM-601](pics_fotosproductos/103/th_crop_asrock-iep-9032e-1.jpg)
![COM-601](pics_fotosproductos/103/th_crop_asrock-iep-9032e-2.jpg)
![COM-601](pics_fotosproductos/103/th_crop_asrock-iep-9032e-3.jpg)
![COM-601](pics_fotosproductos/103/th_crop_asrockfondo-blanco.jpg)
Specifications
Processor system
CPU |
Intel® Pentium/Celeron Braswell SoC Supports Hyper-Threading Technology Default N3160 Quad core 6W processor |
Chipset |
(By CPU) |
BIOS/OS Support |
UEFI |
Watchdog |
1,2…255 Sec |
Expansion slot
PCI |
- |
Mini-PCIe |
By Carrier Board |
mSATA |
By Carrier Board |
PCIe |
7 x PCIe x1 Lane |
Cfast |
- |
M.2 |
- |
Memory
Technology |
DDR3L 1333/1600 MHz SDRAM |
Max. |
8GB |
Storage |
SATA3 (6.0Gb/s) |
Graphics
Controller |
Intel® HD Graphics |
Max. Resolution |
2560 x 1600 |
Ethernet
Rear I/O
VGA |
1 x DDI to VGA, By Carrier Board (Shared with DP) |
HDMI |
1 x DDI to HDMI, By Carrier Board |
DVI-I/D |
- |
Display Port |
2 x DDI to DP, By Carrier Board |
Ethernet |
1 x RJ45 for GbE, By Carrier Board |
USB |
4 x USB 3.0 Ports, By Carrier Board |
Audio |
1 x Line-Out, 1 x MIC-in, 1 x Line- In, By Carrier Board |
Serial |
2 |
Internal connector
USB |
2 x USB 2.0, By Carrier Board |
LVDS/Inverter |
1, By Carrier Board |
Serial |
2 (TX/RX Only), By Carrier Board |
SATA |
4, By Carrier Board |
mSATA |
- |
Mini-PCIe |
2, By Carrier Board |
GPIO |
4 x GPI + 4 x GPO, By Carrier Board |
SATA PWR |
1, By Carrier Board |
SIM |
- |
Power requirement
Power Input |
By Carrier Board |
Environment
Operating temp. |
0ºC–60ºC |
Storage temp. |
- |
Humidity |
- |
Mechanical
