ECS LIVA Z5E PLUS
Business and Industrial use with Flexible Ultracompact Mini PC- Intel® 13th Gen Core™ Processors (TDP 15W) Processors
- Support triple display outputs
- Up to 802.11ax wireless connection
- Dual Gigabit LAN
- Embedded COM Ports to connect industria
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/med_full_ecs-liva-z5e-plus-1.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/med_full_ecs-liva-z5e-plus-2.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/med_full_ecs-liva-z5e-plus-4.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/med_full_ecs-liva-z5e-plus-3.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/med_full_ecslogonegro.png)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/th_crop_ecs-liva-z5e-plus-1.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/th_crop_ecs-liva-z5e-plus-2.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/th_crop_ecs-liva-z5e-plus-4.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/th_crop_ecs-liva-z5e-plus-3.jpg)
![ECS LIVA Z5E PLUS](pics_fotosproductos/2102/th_crop_ecslogonegro.png)
Specifications
- PLATFORM
Intel®Raptor Lake-U U300 SoC
Intel®Raptor Lake-U Core™ i3-1315U SoC
Intel®Raptor Lake-U Core™ i5-1335U SoC
Intel®Raptor Lake-U Core™ i5-1345U SoC (vPRO supported)
Intel®Raptor Lake-U Core™ i7-1355U SoC
Intel®Raptor Lake-U Core™ i7-1365U SoC (vPRO supported) - EXPANSION SLOT
4 x COM Ports
└ COM1 & 2: RS232/422/485 supported
└ COM3 & 4: RS232 supported - MEMORY
Support 2 x SO-DIMM DDR4 3200MHz, up to 64GB
- STORAGE DEVICES
1 x M.2 2280 PCIe Gen4x4/NVME SSDSupport 1 x 2.5” SATA HDD / SSD (optional)
- AUDIO
1 x Combo Jack
- NETWORKING
2 x 2.5 Gbps LAN (LAN 1: i226 LM & i226V vPRO co-layout)
- USB
3x USB 3.2 Gen 2x1 (Front I/O)1 x USB 4 Gen 2×2 Type C (Front I/O)1 x USB 2.0 (Internal Header 2x5)
- VIDEO OUTPUT / INPUT
2 x HDMI (HDMI 1: w/ CEC function; Power on/off only)1 x DP1.4 HBR31 x Type C (alt DP)
- WIRELESS
1 x M.2 2230 WLAN 802.11ax
- POWER
19V/4.74A, 90W
- VESA MOUNT
Supports 75mm / 100mm
- DIMENSIONS (MM)
148 x 120 x 53.9 (mm)
- OS SUPPORT
Windows® 10 IOT
Windows® 11 Home & Pro
Linux - ACCESSORY
ADAPTER / SCREW / VESA MOUNT / QUICK GUIDE
- REMARK
1 x TPM IC Onboard (Optional)
