Handheld ALGIZ RT10 RTK

When you need high-precision positioning in the field, there's a single tool that's rugged, portable and sophisticated enough to get the job done. The rugged Algiz RT10 RTK Android Tablet integrates GPS Real-Time Kinematic (RTK) accuracy and has been specifically designed for GIS and mapping professionals who need highly accurate location data.

Snapdragon 480 5G
- High-end Qualcomm Snapdragon 480 5G processor
Android 11 with GMS
- Latest Android OS security features
Biometric security
- Biometric scanning via a built-in fingerprint reader
RTK positioning
- With u-blox ZED-F9P Multi-band GNSS high precision receiver
Android Enterprise Recommended
- Elevated enterprise requirements validated by Google

Comunicación / Portable
Industria
Seguridad
Transporte

4G
5G
Android
Bluetooth
GPS
Interfaz
IP6X
IPX7
LAN
Lte
Multi-táctil
USB

Specifications

Dimensions

274 mm x 185 mm x 17 mm (10.8” x 7.3” x 0.67”)

Weight

980 g (2.2 lbs)

Processor

Qualcomm® Snapdragon 480 SM4350, 8 cores 2.0 GHz

Graphics

Adreno 619

RAM and Storage

6 GB / 128 GB

Operating System

Android 11 (GMS)
Android Enterprise Recommended

Display

10” capacitive multi-touch
1920×1200 pixels
Sunlight readable, 600 nits

Buttons

Front
Power, volume up/down, F1, F2, F3

Battery

Standard
11700 mAh (44.46 Wh)
User-replacable

Ports

Qualcomm® Quick Charge™ Type-C
x2 Type A USB 3.0 OTG
3.5mm headphone jack
Docking connector
Back connector for expandability
Micro SDXC
x2 Nano-SIM

Communication

Cellular (WWAN)
Global:
4G/LTE (1,2,3,4,5,7,8,12,20,28,34,38,39,40,41)
5G (N41, N78, N79)
*Data only
Wireless LAN
2.4 GHz + 5 GHz
802.11a/b/g/n/ac
PAN
BT V5.1
NFC
13.56 MHz
ISO 14443A/B, ISO 15693
Audio
Rear-facing speaker
Microphone

Positioning

Dedicated u-blox ZED-F9P High precision GNSS receiver
GPS/QZSS, Galileo, GLONASS, BeiDou. SBAS
GNSS Bands
B1I, B2I, E1B/C, E5b, L1C/A, L1OF, L2C, L2OF
Channels
184 channels
Concurrent GNSS
4
RTK Convergence time
10s
RTK Update rate
<20 hz="" strong="">
RTK Precision
0.01m + 1ppm CEP
Features
Anti jamming, anti-spoofing

Cameras

Rear
13 megapixels with auto-focus and flash
Front
5 megapixels

Sensors

Fingerprint
Gyroscope
Accelerometer
Ambient light
e-Compass

Environment

Operating
-20 °C to 60 °C (-4 °F to 140 °F)
MIL-STD-810G, Method 501.5/502.5 Procedure II
Storage
-30 °C to 70 °C (-22 °F to 158 °F)
MIL-STD-810G, Method 501.5/502.5 Procedure I
Drop / Shock
26 drops from 1.2 m (4 ft.)
MIL-STD-810G, Method 516.6 Procedure IV
Vibration
MIL-STD-810G, Method 514.6 Procedures I
Sand / Dust
IP67, IEC 60529
Water
IP67, IEC 60529
Humidity
0% ～ 95% (non-condensing)
MIL-STD-810G, Method 507.5 Procedure II
Altitude
4,572 m (15,000 ft)
MIL-STD-810G, Method 500.5 Procedure I
