IMB-A182
Mini-ITX AMD Embedded G-Series SOC (0ºC – 60ºC)- AMD Embedded G-Series SOC processor(s)
- Support DDR3 1600MHz
- 1 x VGA, 1 x HDMI
- 24 bit dual channel LVDS
- 6 x COM ports, 6 x USB 2.0, 2 x USB 3.0
- 1 x PCIex4, 1x SATA 3.0, 1 x mSATA
- Dual Gbe LAN: 1 x Realtek RTL8111E, 1 x Realtek RTL8111DP to support Dash Function
- 1 x TPM header
/
-
4G
-
5G
-
Bluetooth
-
DC
-
Display Port
-
Fanless
-
Intel
-
Interface
-
LAN
-
Lte
-
POE
-
USB
-
VGA
-
Extended temperature range
-
Wifi
Specifications
Processor system
|
CPU |
AMD-- Embedded G-Series SOC processor(s) GX-420CA: 25W 4Core (2.0G Hz) |
|
Chipset |
SOC |
|
BIOS/OS Support |
UEFI |
|
Watchdog |
0,1,2…255 Sec/Min |
Expansion slot
|
PCI |
NA |
|
Mini-PCIe |
1 ( half size) |
|
mSATA |
1 |
|
PCIe |
- |
|
Cfast |
- |
|
M.2 |
- |
Memory
|
Technology |
Single Channel Up to DDR3 1600 MHz 2 x So-DIMM |
|
Max. |
16GB |
|
Storage |
SATA3 (6.0Gb/s) |
Graphics
|
Controller |
By SOC |
|
Max. Resolution |
-- |
Ethernet
Rear I/O
|
VGA |
1 |
|
HDMI |
1 |
|
DVI-I/D |
- |
|
Display Port |
- |
|
Ethernet |
2 |
|
USB |
6 (4 x USB 2.0 compliant, 2 x USB 3.0 compliant) |
|
Audio |
2 (Mic-in, Line-out) |
|
Serial |
2 (RS232/422/485) |
Internal connector
|
USB |
2 x USB2.0 port (by Header), 1 x USB Type A Con |
|
LVDS/Inverter |
YES (option) |
|
Serial |
4 x RS232 and 4x (1x3) Header toff oer PWR select ofr 2 rear and 2 internal |
|
SATA |
1 x SATA3, 1 x m-SATA |
|
mSATA |
1 |
|
Mini-PCIe |
1 (half size) |
|
GPIO |
4 x GPI + 4 x GPO |
|
SATA PWR |
- |
|
SIM |
- |
Power requirement
|
Power Input |
12V DC-In (4-pin ATX PWR Con)/20-pin ATX PWR con |
Environment
|
Operating temp. |
0ºC – 60ºC |
|
Storage temp. |
- |
|
Humidity |
- |
Mechanical
