InHand Networks IR624-NRF4-WLAN
InRouter IR624 5G/4G Cellular high-speed Industrial IoT enterprise Router With Serial Port 1*RS232+1*RS485 5G Industrial Router The InRouter624 (IR624) series by InHand Networks is designed to assist enterprises in digital transformation. Integrated with 5G/4G, Wi-Fi, VPN, and more, it offers efficient, secure, and intelligent connectivity solutions for various IoT industries. With a multi-level link detection mechanism, the IR624 ensures stable communication for unattended industrial sites. Paired with InHand Networks' DeviceLive IoT management platform, it aids users in achieving centralized cloud management and remote maintenance. This allows for easy monitoring of device status, reducing deployment costs, and enhancing management efficiency.
Industria / IoT
-
4G
-
5G
-
DC
-
Interfaz
-
LAN
-
Lte
-
POE
-
Serie
-
Rango extendido de temperatura
-
Wifi
Specifications
| InRouter624 Hardware Specifications | |
| Item | IR624 |
| Hardware Platform | |
| CPU | 880MHz |
| RAM | 256MB |
| FLASH | 128MB |
| Interfaces | |
| Cellular | 5G, downlink speed of up to 2Gbps, Sub6(450MHz to 6GHz), compatible with 4G/3G |
| Ethernet Port | 4*10/100/1000Mbps，Ethernet, WAN/LAN/VLAN 1.5KV network isolation transformer protection |
| Power Supply | DC9-36V, over-current protection, anti-reverse connection, 2 PIN industrial terminal |
| Serial Port | 1 x RS232 + 1 x RS485 |
| Reset | Reset button |
| SIM Card | 1 x Drawer-type slot, support dual-NANO SIM, 1.8 V/3 V eSIM (Optional) |
| Antenna Interface | 4 x SMA for 5G or 2 x SMA for 4G , 2 x RP-SMA for Wi-Fi |
| Ground Terminal | Supports |
| Indicator | 1 x System, 1 x Cellular, 1 x 2.4G Wi-Fi, 1 x 5G Wi-Fi, 3 x Signal |
| Ground Terminal | Supports |
| Hardware components | |
| RTC | Support |
| Mechanical Specs |
| Dimensions | 127 * 108.2 * 35mm |
| Weight | 544g |
| Protection Rating | IP30 |
| Installation | Din-rail |
| Power rate | |
| Standby power | 370 ~ 480mA@12V |
| Working power | 415 ~ 530mA@12V |
| Peak power | 530mA@12V |
| Ambient Environment | |
| Storage Temperature | -40 ~ 85℃ |
| Ambient Humidity | 5 ~ 95% (no condensing) |
| Operating Temperature | -20 ~ 70℃ |
| EMC | |
| Static |
EN61000-4-2, level 3 |
| Radiation Electric Field | EN61000-4-3, level 3 |
| Pulsed Electric Field | EN61000-4-4, level 3 |
| Surge | EN61000-4-5, level 3 |
| Conducted Disturbance Immunity | EN61000-4-6 ,level 3 |
| Shock Wave Resistance | EN61000-4-12,level 3 |
| Power Frequency Magnetic Field Resistance | EN61000-4-8, horizontal / vertical 400A/m (>level 2) |
| Physical Specs | |
| Shock | IEC60068-2-27 |
| Vibration | IEC60068-2-6 |
| Free Fall | IEC60068-2-32 |
| Certification |
| CE, E-MARK* |
| IR624 Software Specifications | |
| Network Connection | |
| Network Access | APN, VPDN |
| Access Authentication | CHAP/PAP |
| Network Type | WCDMA, TDD LTE/FDD LTE, 5G NR(SA/NSA) (Please refer to the Ordering Guide for frequencies) |
| LAN protocol | ARP, Ethernet |
| WAN protocol | Static IP, DHCP, PPPoE |
| Network Protocol | |
| Protocol & Application | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SSL/TLS, ARP, VRRP, PPP, PPPoE, SSH, DHCP Server, DHCP Relay, DHCP Client, DDNS, Telnet, IP Passthrough |
| IP Routing | Static routing |
| Security | |
| Network Security | Support access control, NAT, port mapping and firewall filtering based on MAC/IP/port/protocol Support Policy-Based Routing |
| Data Security | Supports PPTP, L2TP |
| Reliability | |
| Backup | Interface backup |
| Dual SIM Failover | Supports dual SIM failover |
| Link Detection | Sends heartbeat packets to detect, auto redials when disconnected |
| Embedded Watchdog | Device runs self-detection, auto recovers from malfunctions |
| WLAN (Optional) | |
| Working Mode | AP, Client |
| Security | Open system, shared key, WPA/WPA2 certification WEP/TKIP/AES encryption |
| Wi-Fi Portal | Support |
| Intelligence | |
| DTU Functions | TCP / UDP transparent transmission mode Supports conversion of Modbus RTU to Modbus TCP bridge |
| Monitoring & Alerting | |
| Dash Board | Device information, interface status, and refined traffic statistics |
| Link Monitoring | Link delay, jitter, packet loss, and throughput |
| Log & Alarm | System logs, diagnostic logs, device events |
| QoS | |
| Traffic Shaping | Support |
| Remote maintenance | |
| Remote Access | Support Web/CLI remote access |
| Cloud Management | DeviceLive supports batch management, equipment monitoring, remote maintenance |
| Network Diagnostics | Support Ping, Traceroute and network packet capture tools |
| Configuration Backup | Support configuration import and export |
