LiteMax ISDM-3205-SDM1
32” TFT LCD,800nits,MaxRGB UHD(3840x2160) SDM Solutions- High Brightness 800 nits
- Sunlight Readable
- LED Backlight
- MaxRGB (NTSC 97%)
- Low Power Consumption
- High Color Saturation
- Support Intel® SDM-S
- Storage SSD64GB, RAM 8GB, Wifi Support
- BL MTBF: 100,000 hours
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/med_full_aicsys-rck-310ma-3u-rackmount-chassis-1.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/med_full_aicsys-rck-310ma-3u-rackmount-chassis-2.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/med_full_aicsys-rck-310ma-3u-rackmount-chassis-5.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/med_full_aicsys-rck-310ma-3u-rackmount-chassis-3.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/med_full_aicsys-logo.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/th_crop_aicsys-rck-310ma-3u-rackmount-chassis-1.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/th_crop_aicsys-rck-310ma-3u-rackmount-chassis-2.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/th_crop_aicsys-rck-310ma-3u-rackmount-chassis-5.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/th_crop_aicsys-rck-310ma-3u-rackmount-chassis-3.jpg)
![LiteMax ISDM-3205-SDM1](pics_fotosproductos/517/th_crop_aicsys-logo.jpg)
Specifications
Model Name | ISDM--3205-SDM1 |
Description | 32” TFT LCD,800nits,MaxRGB UHD(3840x2160) SDM Solutions |
Size | 32” |
Display Area (mm) | 698.4(H) x 392.85(V) |
Brightness | 800 cd/m2 |
Resolution | 3840x2160 |
Aspect Ratio | 16 : 9 |
Contrast Ratio | 4500 : 1 |
Pixel Pitch (mm) | 0.181(H) x 0.181(V) |
Pixel Pre Inch (PPI) | 137 |
Viewing Angle | 178°(H),178°(V) |
Color Saturation (NTSC) | 97% |
Display Colors | 1.07G |
Response Time (Typical) | 9.5ms |
Computer | Intel® SDM Core i5-7Y57 Processor |
Storage | 64GB on board |
Memory | 8GB on board |
WiFi + Bluetooth | Intel® Dual Band Wireless AC-8265 |
IEEE WLAN Standard | IEEE 802.11 a,b,g,n,ac |
Bluetooth | 4.2 |
Input Power | AC100~240V |
Power Consumption | 124W |
Dimensions (mm) | 735.4 x 429.8 x 65.3 |
Bezel Size(U/B/L/R) | 16.5/16.5/16.5/16.5 mm |
Weight (Net) | 12.6kg |
Mounting | 100x100, 150x150 |
Operating Temperature | 0 ˚C ~ 50 ˚C |
Storage Temperature | -20 ˚C ~ 60 ˚C |
