Litemax SLD1744-E
17" TFT LCD, 1000 nits LED backlight, 1280x1024- 17" sunlight readable, high brightness (1,000 nits)
- Resolutions: 1280 x 1024
- Industry leading LED backlight
- Aspect ratio of 5:4
- High contrast ratio (1000:1)
- Low power consumption
- BL MTBF: 70,000 hours
Industria / Display
-
DC
-
DVI
-
VGA
Specifications
Model name
SLD1744-E
Description
17" TFT LCD, 1000 nits LED backlight, 1280x1024
Size
17"
Display area (mm)
337.9(H) x 270.3(V)
Brightness
1000 cd/m²
Resolution
1280x1024
Aspect ratio
5:4
Contrast ratio
1000:1
Pixel pitch (mm)
0.264 (H) x 0.264 (V)
Pixel per inch (PPI)
96
Viewing angle
170° (H), 160° (V)
Color saturation (NTSC)
83%
Display colors
16.7M
Response time (Typical)
5ms
Video interface
VGA, DVI-D
Input power
DC 12V
Power consumption
39w
Dimensions (mm)
436x373x61.6
Bezel size (U/B/L/R)
11.18/11.18/8.39/8.39
Weight (Net)
6.33kg
Mounting
VESA 75x75,100x100
OSD key
4 keys (Power switch, menu, +, -)
OSD control
Brightness, color, contrast, H/V position… etc
Operating temperature
0°C ~ +50°C
Storage temperature
-20°C ~ +60°C
Product approval
CE, FCC
