Litemax SLD1968-E
19" TFT LCD, 1600 nits LED backlight, 1280x1024- 19" sunlight readable, high brightness (1,600 nits)
- Resolutions: 1280 x 1024
- Industry leading LED backlight
- Aspect ratio of 5:4
- High contrast ratio (1000:1)
- Low power consumption
- BL MTBF: 70,000 hours
Industria / Display
-
DC
-
DVI
-
VGA
Specifications
Model name
SLD1968-E
Description
19" TFT LCD, 1600 nits LED backlight, 1280x1024
Size
19"
Display area (mm)
376.3(H) x 301.1(V)
Brightness
1600 cd/m²
Resolution
1280x1024
Aspect ratio
5:4
Contrast ratio
1000:1
Pixel pitch (mm)
0.294 (H) x 0.294 (V)
Pixel per inch (PPI)
86
Viewing angle
170° (H), 160° (V)
Color saturation (NTSC)
80%
Display colors
16.7M
Response time (Typical)
5ms
Video interface
VGA, DVI-D
Input power
DC 12V
Power consumption
31w
Dimensions (mm)
396x326x36.5
Bezel size (U/B/L/R)
10.5/10.5/7.9/7.9
Weight (Net)
2.75kg
Mounting
VESA 75x75,100x100
OSD key
4 keys (Power switch, menu, +, -)
OSD control
Brightness, color, contrast, H/V position… etc
Operating temperature
0°C ~ +50°C
Storage temperature
-20°C ~ +60°C
Product approval
CE, FCC
