Litemax SSH2405-Y
24” LCD, 1000nits LED backlight, 1920 x 360 ultra-wide aspect ratio 16:3- Ultra-Wide Screen (16 : 3)
- High Brightness
- Sunlight Readable
- LED Backlight
- Low Power ConsumptionBL MTBF: 100,000 hours
Gaming / DisplayIndustria
Kiosk
Smart City
Transporte
-
Alto brillo
-
DC
-
DVI
-
HDMI
-
VGA
-
Gran angulo de visión
Specifications
Model name
SSH2405-Y
Description
24” LCD, 1000nits LED backlight, 1920 x 360 ultra-wide aspect ratio 16:3
Size
24”
Display area (mm)
597.8(H) x 112.1(V)
Brightness
1000 cd/m²
Resolution
1920x360
Aspect ratio
16 : 3
Contrast ratio
850 : 1
Pixel pitch (mm)
0.3114(H) x 0.3114(V)
Pixel per inch (PPI)
81
Viewing angle
178°(H),178°(V)
Color saturation (NTSC)
81%
Display colors
16.7M
Response time (Typical)
30ms
Video interface
VGA, DVI-D, HDMI
Input power
DC12V
Power consumption
21W / (27.5W with AD board)
Dimensions (mm)
612.7x 132.1 x 12.8
Bezel size (U/B/L/R)
11/6/6/6 mm
Weight (Net)
1.23 kg
Operating temperature
0 ˚C ~ 50 ˚C
Storage temperature
-20 ˚C ~ 60 ˚C
