N3160-NUC IPC
104 x 102mm intel Braswell N3150 (0ºC – 60ºC)- Intel® Braswell N3160 (Fan Design)
- 2 x HDMI, 1 x DisplayPort
- 1 x Giga LAN
- 4 x USB 3.0 (1 x Type C), 1 x Audio-out with MIC-In
- 1 x mSATA, 1 x Mini-PCIe
- Triple display (2 x HDMI, 1 x DisplayPort),Support 4K Display and Playback
Kiosk en
![N3160-NUC IPC](pics_fotosproductos/86/med_full_n3160-nuc-ipc-i1.jpg)
![N3160-NUC IPC](pics_fotosproductos/86/med_full_n3160-nuc-ipc-i2.jpg)
![N3160-NUC IPC](pics_fotosproductos/86/med_full_n3160-nuc-ipc-i3.jpg)
![N3160-NUC IPC](pics_fotosproductos/86/med_full_asrockfondo-blanco.jpg)
![N3160-NUC IPC](pics_fotosproductos/86/th_crop_n3160-nuc-ipc-i1.jpg)
![N3160-NUC IPC](pics_fotosproductos/86/th_crop_n3160-nuc-ipc-i2.jpg)
![N3160-NUC IPC](pics_fotosproductos/86/th_crop_n3160-nuc-ipc-i3.jpg)
![N3160-NUC IPC](pics_fotosproductos/86/th_crop_asrockfondo-blanco.jpg)
Specifications
Processor system
CPU |
ntel® Quad Core Braswell N3150(With FAN) Supports Hyper-Threading Technology |
Chipset |
- |
BIOS/OS Support |
UEFI |
Watchdog |
- |
Expansion slot
PCI |
- |
Mini-PCIe |
1 (half size, supports PCIe x1 & USB) |
mSATA |
1 (Only support SATA) |
PCIe |
- |
Cfast |
- |
M.2 |
- |
Memory
Technology |
Dual Channel DDR3L 1066/1600 MHz SDRAM 2 x SO-DIMM |
Max. |
16 GB |
Storage |
SATA3 (6.0Gb/s) |
Graphics
Controller |
Intel® Gen8 Intel Graphics DX 11*, OGL3.2 |
Max. Resolution |
3840x2160@30Hz |
Ethernet
Rear I/O
VGA |
- |
HDMI |
2 |
DVI-I/D |
- |
Display Port |
1 |
Ethernet |
1 |
USB |
4 (3 x USB 3.0 compliant, 1 x USB 3.0 Type C) |
Audio |
1 (Mic-in, Line-out) |
Serial |
- |
Internal connector
USB |
- |
LVDS/Inverter |
- |
Serial |
- |
SATA |
1 x SATA3 ( 6.0Gb/s) |
mSATA |
1 |
Mini-PCIe |
1 |
GPIO |
- |
SATA PWR |
1 |
SIM |
- |
Power requirement
Power Input |
12V DC-In (DC Jack) |
Environment
Operating temp. |
0ºC – 60ºC |
Storage temp. |
- |
Humidity |
- |
Mechanical
