SINTRONES VBOX-3200-IP65
AMD G-T56N/G-T40E/G-T48E (-40 ~ 70°C(SSD), ambient w/ air)- AMD G-T56N Dual Core APU with Radeon HD 6320
- Wireless Support LTE, 3.5G, WLAN, GPS, GSM/GPRS, Bluetooth
- 9V - 32V DC Power Input
- Smarter Vehicle Power Ignition for Variety Vehicle
- 4 x DI / 2 x DO with Relay 12V / 80mA
- IP65 Level for Water and Dust Proof
/ IPC(Industrial PC)
-
AMD
-
Bluetooth
-
DC
-
DVI
-
GPS
-
Interface
-
IP6X
-
IPX5
-
LAN
-
Lte
-
Serial
-
SSD
-
USB
Specifications
Processor system
|
CPU |
AMD G-T56N Dual Core 1.65GHz AMD G-T40E Dual Core 1.0GHz (Optional) AMD G-T48E Dual Core 1.4GHz (Optional) |
|
Chipset |
AMD A50M Controller Hub |
|
BIOS/OS Support |
- |
|
Watchdog |
1 ~ 255 Level Reset |
Expansion slot
|
PCI |
- |
|
Mini-PCIe |
- |
|
mSATA |
- |
|
PCIe |
- |
|
Cfast |
- |
|
M.2 |
- |
Memory
|
Technology |
2 x DDR3 1333MHz SO-DIMM |
|
Max. |
8GB |
|
Storage |
1 x 2.5” Drive Bay for SATA Type Hard Disk Drive / SSD 1 x SATA DOM |
Graphics
|
Controller |
AMD G-T56N Radeon HD 6320 UVD3 Hardware Video Decoder - MPEG2, MPEG4, H.264 |
|
Max. Resolution |
2560 x 1600 @85Hz |
Ethernet
|
Controller |
2 x Realtek RTL8111E Gb/s Ethernet Onboard Support PXE and Wake On Lan |
|
Connector |
2 x M12 Connectors for GbE |
Rear I/O
|
VGA |
- |
|
HDMI |
- |
|
DVI-I/D |
1 |
|
Display Port |
- |
|
Ethernet |
2 x M12 |
|
USB |
4 x USB 2.0 Ports on Front I/O |
|
Audio |
1 x Line-out, 1 x Mic-in and 1 x Line-in |
|
Serial |
2 x RS-232 with RS-422/485 (Auto Direction Control) |
Internal connector
|
USB |
- |
|
LVDS/Inverter |
- |
|
Serial |
- |
|
SATA |
- |
|
mSATA |
- |
|
Mini-PCIe |
- |
|
GPIO |
- |
|
SATA PWR |
- |
|
SIM |
2 x SIM Card Sockets Supported Onboard |
Power requirement
|
Power Input |
9V - 32V DC Power Input |
Environment
|
Operating temp. |
-40 ~ 70ºC (SSD), ambient w/ air |
|
Storage temp. |
-40 ~ 80ºC |
|
Humidity |
10 ~ 95% (non-condensing) |
Mechanical
|
Format factor |
- |
|
Dimensions |
250 x 150 x 55 mm |
|
Weight |
1780 g (Barebone) |
|
Construction |
Aluminum Alloy |
