SINTRONES VBOX-3610-POE

CPU

Intel Gen 5 Core i7-5650U 2.2GHz up to 3.1GHz

Intel Gen 5 Core i3-5010U 2.1GHz

Intel Gen 4 Core i7-4650U 1.7GHz up to 3.3GHz

Intel Gen 4 Core i5-4300U 1.9GHz up to 2.9GHz

Intel Gen 4 Core i3-4010U 1.7GHz

Intel Gen 4 Dual Core Celeron 2980U 1.6GHz

Chipset

-

BIOS/OS Support

-

Watchdog

Offer 1 – 255 Step

PCI

-

Mini-PCIe

-

mSATA

-

PCIe

-

Cfast

-

M.2

-

Technology

Intel® HD Graphics 5000 / 6000

DirectX Video Acceleration (DXVA) for Accelerating Video

Processing - Full AVC/VC1/MPEG2 HW Decode

Supports DirectX 11/10.1/10/9 and OpenGL 4.0

Max.

4096 x 2304

Storage

2 x 2.5” Drive Bay for SATA Type HDD/SSD, Support RAID 0, 1

1 x mSATA

Controller

Intel® HD Graphics 5000 / 6000

DirectX Video Acceleration (DXVA) for Accelerating Video

Processing - Full AVC/VC1/MPEG2 HW Decode

Supports DirectX 11/10.1/10/9 and OpenGL 4.0

Max. Resolution

4096 x 2304

VGA

1 x VGA

HDMI

-

DVI-I/D

1 x DVI-I

Display Port

-

Ethernet

-

USB

2 x USB 3.0 Ports, 2 x USB 2.0 Ports

Audio

1 x Line-out and 1 x Mic-in (Line-in Optional)

Serial

3 x RS-232 (2 with RS-422/485 (Auto Direction Control))

USB

-

LVDS/Inverter

-

Serial

-

SATA

-

mSATA

-

Mini-PCIe

-

GPIO

-

SATA PWR

-

SIM

1 x SIM Card Socket Supported Onboard with eject

Power Input

9V - 36V DC Power Input

Operating temp.

-40ºC ~ 70ºC (Default CPU 17Watt)

Storage temp.

-40ºC ~ 80ºC

Humidity

0% RH – 95% RH
