Vecow ABP-3000

8th Gen Intel® Core™ U-series Processor (Whiskey Lake) Ultra-slim Fanless Embedded System, 4 GigE LAN with 2 PoE+, 2 DDR4, 4 USB 3.1, 4 COM RS-232/422/485, 16 Isolated DIO, 1 Mini PCIe, 4 M.2, Fanless, Expandable, -40°C to 75°C.

8th Generation Intel® Core™ U-series processor (Whiskey Lake) supports up to 40% greater productivity than former generation
Ultra-slim and cableless design supports wide range temperature of -40°C to 75°C with fanless operation
2 DDR4 2400MHz memory, up to 64GB
Dual independent DisplayPorts display supports up to 4K resolution
4-port USB 3.1 support up to 10Gbps data transfer
4 Independent GigE LAN with 2 IEEE 802.3at PoE+
SIM Socket for 5G/WiFi/4G/3G/LTE/GPRS/UMTS
4 COM RS-232/422/485, 16 Isolated DIO
9V to 50V DC wide range Power Input
Ignition Power Control, TPM 2.0
Expansion : M.2 Key B, M.2 Key M, M.2 Key E and Mini PCIe
Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications

Industria / Sistemas
Seguridad
Smart City
Transporte

3G
4G
5G
DC
Display Port
Sin ventilación
HDD
Intel
Interfaz
LAN
Linux
Lte
POE
Serie
SSD
USB
Rango extendido de temperatura
Wifi
Windows

Specifications

System
Processor	Quad Core Intel® Core™ i7-8665UE/i3-8145UE Processor (Whiskey Lake)
Chipset	Intel® SoC (Cannon Lake)
BIOS	AMI
SIO	IT8786E
Memory	2 DDR4 2400MHz SO-DIMM, up to 64GB
I/O Interface
Serial	4 COM RS-232/422/485 (ESD 8kV)
USB	4 USB 3.1 (External)
Isolated DIO	16 Isolated DIO : 8 DI, 8 DO
LED	HDD, PoE+
SIM Card	2 Internal SIM Card Socket
Expansion
M.2	- 1 M.2 Key E Socket (2230, PCIe) - 1 M.2 Key B Socket (3042/3052, PCIe x2/USB3)
Mini PCIe	1 Mini PCIe Socket for PCIe/USB/SIM Card
Graphics
Graphics Processor	Intel® UHD Graphics 620
Interface	2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
M.2	- 1 M.2 Key M Socket (2280, PCIe x4/SATA, ABP-3000 only) - 1 M.2 Key B Socket (2280, PCIe x2/SATA)
Audio
Audio Codec	Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface	1 Mic-in, 1 Line-out
Ethernet
LAN 1	GigE LAN by Intel® Ethernet Controller I350
LAN 2	GigE LAN by Intel® Ethernet Controller I350

PoE
LAN 3	GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350 with Power On/Off Control
LAN 4	GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350 with Power On/Off Control
Power
Power Input	DC 9V to 50V
Power Interface	Mini DIN
Ignition Control	16 Mode
Remote Switch	3-pin Terminal Block : On, Off, IGN
Others
TPM	Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer	Reset : 1 to 255 sec./min. per step
Smart Management	Wake on LAN, PXE supported
HW Monitor	Monitoring temperature, voltages. Auto throttling control when CPU overheats.
Software Support
OS	Windows 10, Linux
Mechanical
Dimension (W x L x H)	224.0mm x 149.0mm x 32.6mm (8.82" x 5.87" x 1.28")
Weight	1.4 kg (3.09 lb)
Environment
Operating Temperature	-40°C to 75°C (-40°F to 167°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Humidity	5% to 95% Humidity, non-condensing
Relative Humidity	95% @75°C
Shock	- IEC 60068-2-27 - SSD : 50G @ wallmount, Half-sine, 11ms
Vibration	- IEC 60068-2-64 - SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC	CE, FCC, EN50155, EN50121-3-2
